110v Manual Butt Fusion Welding Machine For 50-200mm Pipe

Ask Lasest Price
Brand Name :	MM-Tech
Model Number :	SWT-V200/50MS
Certification :	ISO21307:2011(E),ISO12176-1 and DVS2207/1(08/2007)
Price :	US$1200-US$1600
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	1000 Sets Per Month

Add to Cart

Product Details
Company Profile

110v Manual Butt Fusion Welding Machine For 50-200mm Pipe

50 - 200mm Welding Range Manual Buyy Fusion Pipe Welding Machine

Manual Butt Fusion Welding Machine Introduction:

HDPE Pipe Butt Fusion Welding Machine 50 mm to 200 mm
We are engaged in supplying latest technology HDPE Pipe Jointing Machine
Machine Type: Manual
Input Supply Voltage: 220 V 50 Hz
Power (kva): 3.65 Kva

Manual Butt Fusion Welding Machine Specification:

Technical Parameters	SWT-V200/50MS
Welding Range O.D.	50,63-75-90-110-125-140-160-180-200 mm
Power Supply	(110V*) 220V, 50/60Hz
Rated Power	1.8 kw
Temperature Range	Max. 300ºC
Packing dimension	550480420 mm
Packing dimension	480420570 mm
Gross Weight	95 kgs

SWT-V200MS includes:

*A machine body with 2 aluminum made clamps;
*A Teflon coated heating plate with digital display, equipped with friendly handler;
*A electrical milling cutter;
*Support for milling cutter and heating plate.

Package and Services:

110v Manual Butt Fusion Welding Machine For 50-200mm Pipe

1. Machine Quality Guarantee : 24 months.--- If any parts broken or does not work under normal operating, we are free to provide.

2. We have sufficient stock can dispatch the machine to you immediiately after your payment.

3. Our technicians can provide you with video guidance and 24-hour online service.

Precautions:

1.The machine is used to weld pipes made from PE,PP,PVDF and can not be used to weld material without description otherwise the machine may be damaged or some accident may be resulted in.
2.Don't use the machine in a place with potential hazard of explosion
3.The machine should be operated by responsible ,qualified and trained personnel
4.The machine should be operated on a dry area.The protective measures should be adopted when it's used in rain or on wet ground.
5.The machine is operated by 220v±10%,50Hz,If extended wire should be used,it should have enough lead section according

Our company:

Hebei Mingmai Technology Co., LTD (MM-Tech) is one of comprehensive manufacturer of Thermoplastic Welding Equipment and an experienced professional exporters in China.

Our main products: butt fusion machine, socket fusion machine, electrofusion machine, hot air welders, hot air welding machine, extrusion welders, geomembrane overlap wedge welders, band saw, cutting machine, & welding accessories.
