SWT - NS900D Digital Function 1800W Dam Liner Dedicated Hot Wedge Welder

Hot Wedge Welder Description:

This Geomembrane Welding Machine adopts advanced hot wedge strcuture, it can be welded in many difficult environments. With its high power,high speed and pressure,it welds 1.0mm-3.0mm thickness hot meltin materials such as HDPE,LDPE,PVC,EVA,ECB,PP and others.

Technical parameter:

ltem No.	SWT-NS900D	Welding Speed	0.5M—10M/Min(Adjustable)
Voltage	220v (Customized Acceptable)	Thickness Welded	1.0—3.0mm(SingleLayer)
Frequency	50/60Hz	Welding Temperature	0—450°C(Adjustable)
Power	1800W	Seam Strength	≥85%Welded Layer

The Familiar Malfunction and elimination:

Phenomena	Reason	The was of eliminate
NO turning of the electric machine	Non direction of power supply	Check the power supply whether it is connected or not
	The damage of Insurance wire by burning	Change the insurance wire
	The damage of speeding circuitry board lines By burning	Change the speeding circuitry board
	The damage of electric machine by burning	Change the electric machine
Non speeding of the electric machine	Speeding knob is untightly	Tight the speeding knob
Non speeding of the electric machine	Power pipe was shocked out	Replacing the speeding wire board
Non heating up Thermal wedge	The damage of electric pipe by burning	Replacing the electric pipe
	The damage of temperature control instrument	Replacing the temperature control instrument
	Thermocouple with malfunction	Change the thermocouple
The burning of thermal wedge	The damage of temperature control instrument	Change the temperature control instrument

Construction Drawing:

SWT - NS900D Digital Function 1800W Dam Liner Dedicated Hot Wedge Welder

Packing:

Each set includes:	machine + 3pcs heating elements + Disassembly tools
	+ fuses +manual book

FAQ:

Q: What's the difference between it and SWT-NS900D?
A: SWT-NS900 only has temperature digital display.

Q: What the difference between it and other hot wedge welder?
A: SWT-NS900D has higher power and large welding range.

Q: When is the shipping date?
A: We have sufficent stock can dispatch the machine to you immediately after your payment.

Q: How many days can I receive the machine?
A: You will receive it about 7-10 days after your payment.

Q: Can you put our design and logo on products?
A: Yes, we have professional design service team, we can make any sample as your design, and also can put your logo on products.

Q: What's the payment term?
A: We can accept for PAPAL, T/T. Any other payment as your request.
