HDPE Dam Liner Landfills Dedicated Leakage Tester With Buzzer Alarm
Leakage Tester Presentation:
MMT-7DJ Plastic Film Leak Detector is a high-pressure instrument.
It is a testing equipment used to detect the surface integrity of
leaking plastic film and impermeable film. It can identify damage
points of any size caused by transportation, installation and use,
and maintenance of the plastic film.
Leakage Tester Specification:
| Model | MMT-7DJ |
| Output High Voltage | 1-50KV |
| Detection Thickness | ≤35mm |
| Battery | 12V/2200mA |
| Power Consumption | ≤5W |
| Host Volume | 220*130*88mm³ |
| Leak Point Count | maximum 999 |
| Dimensions | 245*210*300mm |
| Alarm: | buzzer alarm |
Leakage Tester Detection Principle:
MMT-7DJ mulch film leak detector is used to apply a certain amount
of pulse high voltage to the surface of various conductor
anti-corrosion coatings. The air gap breakdown is formed and spark
discharge is generated. At the same time, a pulse signal is sent to
the alarm circuit to make the alarm sound alarm, so as to achieve
the purpose of detecting the anti-corrosion layer.
FAQ:
Q: Is it only suitable for plane detection? What are the requirements
for terrain?
A: The outside soil surface is almost the surface after construction
machinery construction, right? Of course, the flatter the better,
the better to detect. You can press the probe brush on the
geomembrane a little bit harder.
Q: Can the weak spot of the membrane welding be detected?
A: Welding is not strong and cannot be inspected, only the leakage of
the membrane can be measured.
Q: By what principle is the alarm sound?
A: The membrane damage and the ground form a closed loop, leakage
detector detected the current alarm.
Q: How many days can I receive the machine?
A: You will receive it about 7-10 days after your payment.
Q: Can you put our design and logo on products?
A: Yes, we have professional design service team, we can make any
sample as your design, and also can put your logo on products.
Q: What is the principle of leak detection?
A: Principle of pulse voltage.
